“A lightweight XC Race hardtail for fast raids on the trails.”
Lightweight, fast, and surefooted.
A capable, lightweight XC hardtail, the SUPERCHUB is designed to speed effortlessly over the toughest terrain and handle the gnarliest descents. Built around the 29er platform, the SUPERCHUB can take up to 2.4” tyres for maximum float and traction. This bike is made for fast, long recce’s with technical trails thrown in. With its integrated cable routing and 3D print technology, it’s the ultimate in high-end steel MTB technology.
“We wanted a XC bike that could carry us fast over the trails but still handle technical descents.”
A versatile hardtail, the best way to experience off-road.
Whether you’re coming from gravel and looking for a more capable off-road machine, or finding that your full-sus is getting you left behind the group raids, this bike is for you.
“From the dedicated XC racer, to the fast trail hunter, this bike is made to be versatile off-road weapon.”
Use This Bike For…
XC Race ▲▲▲▲▲
Trails ▲▲▲▲▲
Singletrack ▲▲▲▲▲
Ready to Order?
FRAMESET £4200 inc VAT
(AS PART OF A FULL BUILD)
FULL BUILDS STARTING AT £7k
ALL builds INCLUDE
Custom geometry, 3D printed stainless dropouts and seat cluster, Quirk Custom Select tubing, ULTRA-RAW or CANDY-RAW paint, Chris King headset, your choice of Wireless, Di2, or mechanical cable routing.
Specifications
29x2.4”
Max Tyre
100/120mm
Fork Travel
T47 92mm
BB Standard
180mm
Max Rotor
Boost
Native Spacing
31.6mm
Seat Post
INTEGRATED CABLE ROUTING
Fully integrated cable routing protects cables from strikes, improves ease of cleaning, and looks so good!
BOOST SPACING
We build the SUPERCHUB with boost spacing for its improved clearance and increased wheel/frame strength.
3D SEAT CLUSTER
Printed in stainless steel, the cluster seamlessly joins top tube to seat stays, increasing tyre clearance and frame compliance with thin wall straight stays.
INTEGRATED SEAT CLAMP
Recessed inside the top tube, our integrated seat clamp invisibly sits within our 3D printed seat cluster.
3D DROPOUTS
In-house designed 3D stainless dropouts improves compliance, increases strength and reduces weight.
LIGHTWEIGHT
At 1.9kg for a large frame, sub 10kg full builds are easily within reach using mid-high end parts.
54ID OVERSIZED HEADTUBE
Unique to the SUPERCHUB, our in-house designed 54ID headtube improves strength and reduces weight with recessed 1.5” upper and lower bearings.
29R PLATFORM
Clearance for 29x2.4” tyres increases float and traction in all conditions.
XC Race Geometry
We designed our XC Race geometry to take the best features of modern MTB design and tune it to meet the demands fast XC events. We slightly slackened the head angle for better rolling and stability on rough terrain, and raised the BB offers for spirited handling. The longer rear end make the bike climb like a goat without sacrificing cornering ability.
Build Details
Standard with every frame
Quirk 3D printed dropouts
Integrated hidden bolt seat clamp
Integrated cable routing
Oversized 54ID headtube
Custom Quirk headbadge
Signature paint
Front and rear thru-axle skewers
Choose between
SRAM XX1/X01/GX EAGLE AXS | SRAM XX1/X01/GX EAGLE | Shimano XT 1x12 | Shimano SLX 1x12
ENVE M525 | Zipp 3ZERO MOTO |ENVE Foundation AM30 | Hunt XC Wide
Fabric ALM | Scoop | Line saddle with carbon or steel rail
ENVE M5 |Ritchey WCS | PRO Tharsis |Ritchey WCS Alloy
Ready to Order?
FRAMESET £4200 inc VAT
(AS PART OF A FULL BUILD)
FULL BUILDS STARTING AT £7k
ALL builds INCLUDE
Custom geometry, 3D printed stainless dropouts and seat cluster, Quirk Custom Select tubing, ULTRA-RAW or CANDY-RAW paint, Chris King headset, your choice of Wireless, Di2, or mechanical cable routing.
